Page 7 - TDK Lambda - Products Selection Guide

■ DC-DC
■ DC-DC
Input Voltage (VDC) Output Terminal Type Output Voltage (V) Output Current (A)
2.4 to 4.5 to 3 to 3 to 9 to 9 to 9 to 9 to 18 to 18 to Series Single Dual Triple Features DIP SMD SIP -2K -30 -3.3 0.6 0.8 1.5 2 3.3 5 5.5 8 8.5 15 16.5 24 30 40 48 2K 0.1 0.15 3 4.5 5 6 8 10 12 14 20 33 40 45 60 Warranty Page
5.5 14 14 17 18 40 36 53 32 60 (Year)
Non-Isolated

● ● i3A, i6A ● Wide output adjustment POL ● Variable ● ● ● ● ● 3 47,
49
● ● ● iAF, iAH ● 20〜40A POL converter ● Variable ● ● 3 48
● ● ● iBF, iBH ● 12〜20A POL converter ● Variable ● ● 3 48
● ● iCF, iCG, iCH ● SMT DOSA 2 POL converter ● Variable ● ● ● ● 3 48
● ● i7A ● Step down converter ● ● ● 3 49
● ● i7C ● Buck-boost converter ● Variable ● ● ● 3 49
● ● RGA ● Ruggedized buck-boost converter ● Variable ● ● ● 3 50
● ● ● RGB ● Ruggedized step down converter ● Variable ● ● ● 3 50
● RGC ● Ruggedized buct-boost converter ● Variable ● ● 3 50

Input Voltage (VDC) Output Terminal Type Output Voltage (kV) Output Current (mA)
10.8 to 13.2 10.8 to 16.5 11 to 13 Series Single Dual Triple Features DIP SMD SIP -2 -1.5 -1 -0.47 -0.35 -0.30 -0.18 0.18 0.30 0.35 0.47 1 1.5 2 0.7 1 1.3 1.5 2 5.6 7 10 15 Warranty Page
(Year)
● ● ● CHVM ● Programmable output voltage (Voltage or resistance) ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 1 40

■ DC-DC

Input Voltage (VDC) Output Voltage (V) Output Power (W)
Warranty
24 48 110 280 2W # 4N # 4W # Series Features 1.2 1.5 1.8 2.5 3.3 5 9.6 11.2 12 13.8 15 18 24 28 48 30 50 65 75 85 90 100 120 150 200 300 350 400 450 500 600 700 1200 (Year) Page
● PH-A280 Flagship HVDC input power module ● ● ● ● ● ● ● ● ● ● ● ● ● ● 5 43
● ● PAF Full brick size, 100°C baseplate temperature, 1.5kVDC isolation ● ● ● ● ● ● ● 2 42
● ● PAH 1/2 brick size, 100°C baseplate temperature, 1.5kVDC isolation ● ● ● ● ● ● 2 42
● ● CN-A For railway related instruments, IEC61373 shock & vibration ● ● ● ● ● ● ● ● ● ● 5 Web
● CN-B 1/2 brick size, IEC 61373 shock & vibration, Current share function ● ● ● ● ● ● ● ● ● ● 5 43
Heavy duty environment,
● ● HQA 1/4 brick size, 115°C baseplate temperature, 2.25kVDC isolation ● ● ● ● ● ● ● ● 3 44
● ● GQA 1/4 brick size, 105°C baseplate temperature, 1.5kVDC isolation ● ● ● ● ● ● ● 3 44
● iQK 1/4 brick size, 707VDC isolation ● ● 3 45
● ● ● iQE, iQG, iQL 1/4 brick size, 1.5kVDC isolation ● ● ● ● ● ● ● ● 72W to 504W 3 45
● iEA, iEH 1/8 brick size, 1.5kVDC isolation ● ● ● ● ● 48W to 300W 3 44
● iSA 1/16 brick size, 1.5kVDC isolation ● ● ● ● ● ● ● 36W to 82.5W 3 47
# 2W: 9 to 40VDC 4W: 18 to 60VDC 4N: 48 to 56VDC
■ AC-DC

Input Voltage (VAC) Output Voltage (V) Output Power (W)
85 to 265 85 to 130 170 to 265 Series Features 1.2 1.5 1.8 2.5 3.3 5 9.6 12 15 18 24 28 48 360 30 50 65 75 85 100 120 150 200 300 350 400 450 500 600 700 1000 1500 (Year) Page
Warranty
● ● PFH 4×2.4", 3kVAC isolation, with PFC ● ● ● ● 3 40

● PFE-F/PFE-FA Full brick size, Parallel operation ● ● ● ● ● 5 41
● PFE-SA Full brick size ● ● ● ● ● ● 5 41
● PF-B Power factor correction module ● ● 5 41
* Please refer to our website product page of each product for more information.
