Page 9 - TDK Lambda - Products Selection Guide

Function Rated Current (A)
Power High Frequency Noise High Voltage Pulses Low Leakage DIN Rail Output Inverter *1
Supply Performance Case Shape Terminal Structure Correspondence Correspondence Current *1 Mount *1 Correspondence Series 0.5 1 2 3 4 5 6 10 16 20 30 40 50 60 80 100 150 200 250 300 400 Page
● - - - - RPE ● ● ● 52
● - - - - RPE-R ● ● ● 52
● - ● - - RPE-L ● ● ● 52
● - ● - - RPE-RL ● ● ● 52
● ● - - - RPA ● ● 52
● ● - - - RPA-R ● ● 52
IEC Inlet Faston #250 *2
● ● ● - - RPA-L ● ● 52
● ● ● - - RPA-RL ● ● 52
● - - - - RPE-F01 ● ● 52
● - - - - RPE-F02 ● ● 52
● - ● - - RPE-F01L ● ● 52
● - ● - - RPE-F02L ● ● 52
● - - - - RSEG ● ● ● ● ● ● 52
Pin Terminal
● ● - - - RSAG ● ● ● ● ● ● 52
● - - - - RSEC ● 52
Faston #110 *2 ● - - - - RSEL-A ● ● ● ● ● 52
● - ● - - RSEL-AL ● ● ● ● ● 52
● - - - - RSEL-W ● ● ● ● ● 52
Small Size UL1015 Wire ● - ● - - RSEL-WL ● ● ● ● ● 52
● ● - - - RSEL-M ● ● ● ● ● 52
● ● - - - RSAL-A ● ● ● ● ● 52
Faston #110 *2
● ● ● - - RSAL-AL ● ● ● ● ● 52
● ● - - - RSAL-W ● ● ● ● ● 52
UL1015 Wire
● ● ● - - RSAL-WL ● ● ● ● ● 52
DIN-RSEV
● - - (separately sold) - RSEV ● ● ● ● ● 53
● - - - - RSEN ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● *3 53
● - ● - - RSEN-L ● ● ● ● ● ● 53
● - - ● - RSEN-D ● ● ● ● ● ● 53
● - ● ● - RSEN-LD ● ● ● ● ● ● 53
● ● - - - RSAN ● ● ● ● ● ● ● ● ● 53
● ● ● - - RSAN-L ● ● ● ● ● ● 53
● ● - ● - RSAN-D ● ● ● ● ● ● 53
Block Terminal ● ● ● ● - ● ● ● ● ● ● 53
（Self-up Screw） RSAN-LD
Low *3
Profile ● - - - - RSHN ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 53
● - ● - - RSHN-L ● ● ● ● ● ● 53
● - - ● - RSHN-D ● ● ● ● ● ● 53
● - ● ● - RSHN-LD ● ● ● ● ● ● 53
● ● - - - RSMN ● ● ● ● ● ● ● ● ● *3 53
● ● ● - - RSMN-L ● ● ● ● ● ● 53
● ● - ● - RSMN-D ● ● ● ● ● ● 53
● ● ● ● - RSMN-LD ● ● ● ● ● ● 53
Block Terminal ● - - - - RSKN ● ● ● ● 53
*1 L： For low-leakage (current to 30A), D： For a DIn -rail (current to 30A) *2 "Faston" is a registered trademark of TE Connectivity *3 See our website product page for details about safety standard certification of models enclosed in blue boxes.
